Ferrite HF Compression Driver Model D-350

Model 350
Throat 1 Inch
Nominal impedance 8 Ohm
Nominal Power Handling 35 Watt
Continuous Power Handling 70 Watt
Sensitivity(1W/1M) 107 +-2dB
Frequency Range(-10dB max) 1300 – 20000 Hz
Voice Coil Diameter 1.35 Inch
Voice Coil Material CCAW
Voice Coil Former Kapton
Diaphragm Material Titanium, Phenolic
Magnet Type Strontium Ferrite
Magnet Size 90mm
Cover(or Adaptor) Material Plastic
