Ferrite HF Compression Driver Model D-350
Model | 350 |
Throat | 1 Inch |
Nominal impedance | 8 Ohm |
Nominal Power Handling | 35 Watt |
Continuous Power Handling | 70 Watt |
Sensitivity(1W/1M) | 107 +-2dB |
Frequency Range(-10dB max) | 1300 – 20000 Hz |
Voice Coil Diameter | 1.35 Inch |
Voice Coil Material | CCAW |
Voice Coil Former | Kapton |
Diaphragm Material | Titanium, Phenolic |
Magnet Type | Strontium Ferrite |
Magnet Size | 90mm |
Cover(or Adaptor) Material | Plastic |
